This turnkey packaging line brings together a flow wrapping machine and an automatic cartoner into one smooth, start-to-finish production system.
How it works:
The flow wrapper starts by sealing products inside protective
plastic film. From there, an automated transfer system moves these
wrapped items directly into the cartoning machine's infeed area.
The cartoner then accurately places the flow-wrapped products into
pre-formed boxes or cartons — finishing the secondary packaging
stage without any hands-on involvement.
What it produces:
This continuous sequence — from initial film wrap to final boxed
package — is designed for high-speed operation across many
industries. Examples include:
Food & beverage (snacks, candies, baked goods)
Health products (blister packs, stick packs)
Cosmetics (tubes, powder compacts)
Consumer goods (electronics, hardware)
Why it stands out:
Full automation means big labor savings
Less product handling boosts hygiene and reduces damage
Compact, integrated design saves floor space
Synchronized operation ensures uniform packaging quality
Throughput can scale to meet changing production needs
Model | DS-100 | DS-120 | DS-250 |
Packing Speed | 40~60 boxes/min | 30~50 boxes/min | 30~50 boxes/min |
Box Size | L:60~220mm | L:80~250mm | L:150~320mm |
W:20~125mm | W:100~160mm | W:100~180mm | |
H:15~60mm | H:40~90mm | H:90~110mm | |
Air Consumption | ≥0.6 mpa, 20 m³/h | ||
Power Supply | 220V/380V, 50HZ | ||
Machine Power | 4.5KW | 5.5KW | 6.5KW |
Machine Size | 3425*1390*1771mm | 3450*1450*1800mm | 4200*1650*1850mm |
Machine Weight | 1200KG | 1600KG | 2500KG |
A. Bag Former
Comes with an adjustable former — bag length and width can be
changed to fit different product sizes.
B. Middle Heat Sealing Device
Features independent temperature control for fast, reliable film
sealing.
E. Output Conveyor
Sends finished cartons onward to the next stage of the line.
Defect Rejection Unit
Automatically pulls out any defective cartons.
Counter & Batching
Monitors total output and organizes cartons into batch sets.
1. What products can the BG-350 machine pack?
The BG-350 packs solid soap bars, soap bowls, bath soap, laundry soap, and toilet soap. It handles both rectangular bars and round/oval soap bowls with adjustable forming tube and sealing jaws.
2. What is the packing speed of the BG-350?
The packing speed is adjustable, typically 30–100 packs per minute depending on product size and film type. The BG-350 is known for reliable high-speed performance.
3. What is a pillow bag packing machine?
A pillow bag packing machine (flow wrapper) wraps products in plastic film, seals the edges, and cuts individual packs – creating a pillow-shaped package. It is fully sealed and ready for sale.
4. Can this machine pack both bar soap and soap bowls?
Yes, the BG-350 handles both bar soap and soap bowls. Changing between product shapes takes 5–10 minutes – adjust the forming tube and sealing jaws via the control panel.
5. What film materials are compatible with the BG-350?
The BG-350 works with most heat-sealable films including polyethylene (PE), polypropylene (PP), OPP, and laminated films. The sealing temperature is adjustable for different materials.
|
|
